380 Synergy Series Digital Weight Indicator
The 380 Synergy Series Digital Weight Indicator is a compact, portable solution designed for simple, reliable weighing wherever you need it. With an easy-to-read LCD display and alkaline battery power, the 380 is ideal for mobile or space-limited applications where flexibility matters. Operators can quickly perform tare functions using push-button or keyed tare, and built-in communication ports make it easy to connect to printers, PCs, or other devices for data output.
Key Features:
- LCD display for clear visibility
- Alkaline battery powered for portable operation
- Push-button tare and keyed tare entry
- Two communication ports for peripheral connections
- Configurable print formats for flexible reporting
Available Options:
- Time/date
- External power supply
Power
- Battery Power: Four alkaline C-cell batteries (not included)
- Optional External Power: 115/230 VAC to 12 VDC adapter
Power Consumption
- 6 W max with optional external power adapter
Battery Life
- 100 hours with one 350Ω load cell, no backlight
- 45 hours with four 350Ω load cells, low backlight
- 20 hours with eight 350Ω load cells, low backlight
Load Cell / Excitation
- Excitation Voltage: 5 VDC
- Load Cell Capacity: 8 × 350Ω or 16 × 700Ω load cells
Analog Performance
- Analog Signal Input Range: -0.3 mV to +30 mV
- Common Mode Voltage: 0.7 V to 3.3 V
- Analog Signal Sensitivity: 1 μV/graduation recommended
A/D Sample Rate
- Gen 1: 5, 6, 10, 12, 20, 25, 40, 50, 80, 100 Hz (software selectable)
- Gen 2: 6, 8, 12, 15, 30, 50, 60, 100, 120 Hz (software selectable)
Resolution
- Internal: 8,000,000 counts
- Display: 100,000
System Linearity
- Within 0.01% full scale
Communication Ports
- RS-232: One full-duplex
- USB: One USB 2.0
Display & Operator Interface
- Annunciators: g, lb, t, tn, kg, oz, battery level, PT, LT, gross, zero, unstable, net
- Display: Six 1 in (25 mm) tall LCD digits
- Keys/Buttons: Five tactile buttons
Physical
- Dimensions (L × W × H): 11.58 × 4.53 × 8.57 in (294 × 115 × 218 mm)
- Weight: 6.25 lb (3.0 kg)
Environmental
- Certified Temperature Range: 14°F to 104°F (-10°C to 40°C)
- Industrial Temperature Range: 14°F to 122°F (-10°C to 50°C)
Enclosure / Rating / Material
- Rating: IP66
- Material: 304 stainless steel
Warranty
- Warranty: Two-year limited
Compliance
- EMC Immunity: 10 V/m
Approvals
- NTEP: 21-051 Class III/IIIL, 10,000 d
- Measurement Canada: AM-6184
- Certifications: CE Marked, UKCA, cULus Listed, IEC
The 380 Synergy Series Digital Weight Indicator is a compact, battery-powered solution for straightforward weighing applications like portable warehouse scales and material handling. With flexible mounting options, it can be installed almost anywhere to keep weight data visible where it’s needed.
It delivers up to 100 hours of operation, features a simple five-button keypad, and includes RS-232 and USB ports for easy connection to peripherals. Configurable print formats help you output only key information, with optional time/date and an external power supply available.
Built in an IP66 stainless steel enclosure, the 380 is dust-tight and washdown-ready, with a bright six-digit LCD display for clear viewing.
