ACII™ Aircraft Scale System

The ACII™ Series Scales are a low cost and reliable scale system available to operators for weighing light aircraft to determine center of gravity. The low cost of this series offers complete justification for purchasing an ultra-efficient scale system versus outsourcing the work to an independent weighing service.

Scale Specifications

Capacity:
4,500 lb (2,200 kg) | 7,500 lb (3,400 kg) | 15,000 lb (6,800 kg) per system (3 pads)

Graduation:
1 lb (0.5 kg)

Accuracy:
± 0.1% of reading or 0.02% of load cell capacity — whichever is greater

Environmental

Humidity:
10% to 95% non-condensing

Temperature Range:
-20° to 150°F (-28° to 65°C)

Electrical

Battery Type:
Standard alkaline or rechargeable AA

Battery Life:
300 hours

RFX™ Wireless Handheld Indicator

Controls:
On/Off, Zero, Backlight, Print, Clear, Store/Enter, Recall, Menu, Show Arms, Show Weight, Numeric Keypad, Total, Clear/Tare

Views:
Up to six scales, scale layout, scale list, Gross/Tare/Net

Display:
4 x 20-digit LCD (0.5" / 13 mm characters)

Power:
Standard alkaline or rechargeable AA batteries

Battery Life:
40 hours

Key Features

Fully Integrated RFX™ Wireless Weighing Technology
Handheld Indicator controls all scale functions
Available Capacities: 4,500 lb (2,200 kg) • 7,500 lb (3,400 kg) • 15,000 lb (6,800 kg) per system
Calculates Center of Gravity for precision applications
Connectivity: RS232 and USB output on indicator
Large, Easy-to-Read LCD Display on the indicator
Battery Life: Standard AA rechargeable batteries
- Up to 300 hours in scales
- Up to 40 hours in indicator

RFX™ Wireless Handheld Weighing Indicator

Operates up to six scales simultaneously
Controls scale functions directly from the indicator, including On/Off and Zero
Displays individual weight, cumulative total, and center of gravity
Stores and recalls up to ten arm records
Provides continuous or on-demand print outputs for up to six scales
Includes a “Read-Only” mode for use with ACWeigh™ Software
Uses standard AA rechargeable batteries with up to 40 hours of runtime
